Angular × web worker
2020-07-05

继前段时间瞎折腾 Angular 应用性能之后,页面性能确实有所提升,但感觉还有提升空间。想到此前一直缠绕在心中的 Web Worker,于是耐不住萌(ji)动(mo)的心,准备再接再厉,来一顿骚操作,让页面更加丝滑。

升级 Angular

此前项目的 Angular 版本是 v7,足够支撑所有的业务功能了。如果没有足够充分的理由,强烈不建议这种大版本升级(v7 -> v10.0.0)!!!强烈不建议这种大版本升级(v7 -> v10.0.0)!!!强烈不建议这种大版本升级(v7 -> v10.0.0)!!! 不要问我为什么,问就是 “谁升级谁知道”。😔……

但是,想要在 Angular 应用中体验 Web Worker,则必须版本至少是 8.0。写原生 js?没问题,但是既然官方支持了,所有的配置、最佳实践啊都是现成的,它不香吗。正好体验一下 Ivy :)

“诸位,青春可是永无止境的!” - 【凯皇

Might Guy

所以,尽情绽放吧,少年!哈哈哈哈哈哈哈哈哈

完整文档请参考此官网链接

升级依赖项 (可选)

我是使用如下命令一次性升级所有的依赖项(不推荐,但是我这个项目小,所以无所谓啦):

1
ng update --all --force

尝试运行项目,解决编译时/运行时的警告/错误提示 (可选)

毕竟,从 7 到 10,步子有点大,很多 breaking changes,不仅仅是 Angular 本身,包括我项目用到的 NG ZORRO 等等。

我的项目中遇到的问题有(大概记录一下,不记得每个改动了):

  • 更改所有 /deep/::ng-deep
  • nzTooltip 移除 nzTitle,推荐使用 nzTooltipTitle
  • nzTable 新的排序方式
  • nzModal API 下,nzGetContainer 设置非空时,弹出框正文可能被遮挡

跑起来,确保升级之后应用仍可以正常运行且编译(很重要!!!)

一般情况下都是可以的正常运行的。真碰见问题,问 Github 或者搜索引擎。

好了,终于可以进入正题啦!

在项目目录中,创建一个基础的 Web Worker

1
ng generate webWorker [name]

参考链接

查看项目变化

此时 Angular CLI 会自动处理好所有变更。比如添加 tsconfig.worker.json、修改 angular.json、添加 web worker 文件等等。

编写 web worker 文件

一般情况下,web worker 是需要操作请求服务器数据的,所以这里简单贴一下请求代码

xxxx.worker.ts 文件:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
/// <reference lib="webworker" />

// importScripts('./worker-common.model');
import { WorkerMessage, WorkerAction } from './worker-common.model';

addEventListener('message', async ({ data }) => {
if (data) {
const theMessage = data as WorkerMessage;
const theData = theMessage.data;
const theAction = theMessage.action;

let responseMessage: WorkerMessage;
if (theAction === WorkerAction.FetchCheckpoints) {
const tagID = +theData;
if (typeof tagID !== 'number') {
// throw new Error('tagID should be number');
return postMessage(new Error('tagID should be number'));
}
const responseData = await fetchCheckpointsByTag(+theData);
responseMessage = new WorkerMessage(responseData, theAction);
} else {
// if (action === WorkerAction.Ping)
const content = (theData || '').split('').sort().join('');
responseMessage = new WorkerMessage(content, theAction);
}
return postMessage(responseMessage);
} else {
console.error('data of MessageEvent is empty');
}
});

/// localStorage is not available in web worker
// https://developer.mozilla.org/en-US/docs/Web/API/Web_Workers_API/Functions_and_classes_available_to_workers
/** caching */
const __STORAGE__ = new Map<string, any>();

/** generate key for localStorage */
const genStorageKey = (...parameters) => {
// arguments.callee is also not availabe in web worker
return (parameters || []).join(':');
};

const fetchCheckpointsByTag = async (tagID?: number) => {
const checkpoints = await fetchCheckpoints();
if (tagID) {
const checkpointIDs = (await fetchCheckpointTagMap()).filter(_ => _.TagID === tagID).map(_ => _.CheckPointID);
const hashMap = new Set(checkpointIDs);
return checkpoints.filter(_ => hashMap.has(_.ID));
} else {
return checkpoints;
}
};

type CheckPoint = { ID: number, Title: string };

/** function to fetch checkpoints */
const fetchCheckpoints = async () => {
const storeKey = genStorageKey(fetchCheckpoints.name);
let checkpoints: Array<CheckPoint> = __STORAGE__.get(storeKey);
if (!(Array.isArray(checkpoints) && checkpoints.length)) {
// no data stored in localStorage
const resp = await fetch('http://localhost:44316/api/CheckPoints', {
method: 'POST',
credentials: 'include'
});
checkpoints = await resp.json();
__STORAGE__.set(storeKey, checkpoints);
}
return checkpoints || [];
};

type CheckPoint_Tag_Map = { CheckPointID: number, TagID: number };
const fetchCheckpointTagMap = async () => {
const storeKey = genStorageKey(fetchCheckpointTagMap.name);
let checkpointTagMap: Array<CheckPoint_Tag_Map> = __STORAGE__.get(storeKey);
if (!(Array.isArray(checkpointTagMap) && checkpointTagMap.length)) {
const resp = await fetch('http://localhost:44316/api/CheckPointTagMap', {
method: 'POST',
credentials: 'include'
});
checkpointTagMap = await resp.json();
__STORAGE__.set(storeKey, checkpointTagMap);
}
return checkpointTagMap || [];
};
worker-common.model.ts 文件
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24

/** enumerator for all worker actions */
export enum WorkerAction {
Ping,
FetchCheckpoints
}

export enum WorkerStatusCode {
Initial,
OK,
Error,
Empty,
ToBeContinued
}

export class WorkerMessage {
constructor(
public data: any,
public action: WorkerAction
) {

}
public status?: WorkerStatusCode = WorkerStatusCode.Initial;
}

编写 *.component.ts 文件

同样,简单示例一下,xxxx.component.ts 文件:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27

ngOnInit(): void {
// register web worker
if (typeof Worker !== 'undefined') {
this.webWorker = new Worker('../xxxx.worker', { type: 'module' });
this.webWorker.addEventListener('message', ({ data }) => {
const theMessage = data as WorkerMessage;
const theAction = theMessage.action;
if (theAction === WorkerAction.FetchCheckpoints) {
this.qwCheckPoints.response.Data = theMessage.data || [];
this.qwCheckPoints.status = Utility.isNotEmptyArray(this.qwCheckPoints.response.Data) ?
QueryStatus.SUCCESS : QueryStatus.EMPTY;
}
});
this.webWorker.postMessage(new WorkerMessage(null, WorkerAction.FetchCheckpoints));
} else {
// Web workers are not supported in this environment.
// TODO: You should add a fallback so that your program still executes correctly.
console.log('The browser doesn\'t support Web Worker.');
}
}

someAction(tce) {
const tagID = tce.index === 0 ? 0 : (this.qwCheckPointTags.response.Data[tce.index - 1] || {}).ID;
// this.qwCheckPoints.query(tagID);
this.webWorker.postMessage(new WorkerMessage(tagID, WorkerAction.FetchCheckpoints));
}

拉出来遛一遛

search Emoji 搜索工具

emmmm,一切都按照预期走了,没什么问题。除了:Google Chrome 调试 Web Worker 真的是鸡肋!!!以后真的在项目中大量使用了再说吧。。。。。。
